Sommer Cable
|SKU: SC-BINARY-234-FRNC
SC-Binary 234 AES/EBU MKII-kabel, 2×0,34 mm², FRNC
Beskrivning
SC-Binary 234 AES/EBU MKII-kabel, 2×0,34 mm², FRNC
The Binary 234 AES/EBU MKII (FRNC) is an outstanding cable for the transmission of digital signals in the 110 Ω AES/EBU and DMX data format. Its shielding is provided by an aluminum-vaporised fleece and a helical copper mesh screen with 100 % coverage. So it offers a very good protection against electric and magnetic interferences. This cable ensures an error-free data transfer over distances of up to 1000 metres.
| Properties | Analog, Digital 110 Ω AES/EBU, FRNC flame retardant, Halogen-free/LSZH, OFC | |
|---|---|---|
| Application | DMX | |
| Application area | ELA 100 V, Installation, Mobile outdoor/indoor, Stage/live, Studio/Broadcast | |
| Colour | black | |
| Signal transmission | symmetrical | |
| Construction | (2LI2Y0,34mm²)(ST)DY | |
| Jacket material | FRNC | |
| Jacket Ø | 5,60 mm | |
| Inner conductor | 2 × 0,34 mm² (AWG 22), Ø 0,66 mm | |
| Shielding | Copper spiral shielding (100 %) | |
| Conductor insulation | Foam PE, Ø 1,50 mm | |
| Impedance | 110 Ω | |
| Weight | 43 g/m | |
| Fire load | 0,17 kWh/m | |
| Temperature | -40 … +80 °C | |
| Packing | 100 m spool | |
